63A 2 Pole 30mA RCD
Replacement Product
63A 30ma - 2 Pole - Type A - DC Sensitive RCCB - 2 Module
Part Code:
CDA263U
Priced per 1
Product Details
Part Code:
CDC263U
- Trip free mechanisms
- Can be padlocked either on or off
2 Pole RCCB 30mA Sensitivity (25A to 100A). Complies with BS EN 61008 IEC1008. Sensitivity: 30mA. Terminal capacity: Rigid 25mm², Flexible 16mm². Rectangular flag indicates Red = closed, Green = open. Oval flag indicates trip: Yellow = tripped. Trip free mechanism. Can be padlocked either on or off. Operating Voltage: 110-230Vac Width: 35mm
Specifications
| Breaking Capacity | 1.5kA |
| Current Rating | 63A |
| EAN | 3250611614982 |
| Manufacturer Part Code | CDC263U |
| Mounting Type | DIN Rail |
| Number of Poles | 2 Pole |
| UNSPSC Code | 39121614 |
