Wago

5 Way Compact Splicing Connector, 4mm [Pack of 25]

Wago

5 Way Compact Splicing Connector, 4mm [Pack of 25]

Part Code: 221-425
Call for price

Stock Availability
Please contact your local store for details
FREE delivery over £50 ex. VAT
Product Details
Part Code: 221-425

Enjoy convenient electrical installations with splicing connector with levers. From intercom system wiring to electric ovens connecting various conductor types is quick and easy with WAGO's practical 221 Series splicing connector. This product has a rated voltage of 450V and a rated current of 32A, making it suitable for high-load applications. Strip lengths must be 11mm when connecting conductors to splicing connector with levers. Featuring conductor terminals along with CAGE CLAMP®, this connector is highly versatile. Our CAGE CLAMP® connection provides a convenient and maintenance-free way to connect all types of conductors. You do not need to prepare the conductor in any way, such as crimping ferrules. The item's dimensions are 30 x 8.4 x 18.6mm (width x height x depth). Depending on the type of conductor, splicing connector with levers is designed for conductor cross sections ranging from 0.2mm² to 4mm².

Specifications
Contact Material Copper
Manufacturer Part Code 221-425
Material PC (Polycarbonate)
Number of Ways 5 Way
