32A TP 10kA Type B MCB
32A TP 10kA Type B MCB
Part Code:
NBN332A
Stock Availability
FREE delivery over £50 ex. VAT
Product Details
Part Code:
NBN332A
- Protection of circuits against short circuits
- Protection of circuits against overload current
- The state of isolation is clearly indicated by the "OFF" mechanical position on the toggle with the green colour
32A triple Pole MCB 10kA Type B. Type B tripping characteristics. Complies with BS EN 60898 (10kA), BS EN 60947-2 (15kA). Voltage rating: 230 - 400V. Connection capacity: Rigid conductor 35mm² Flexible conductor 25mm² Width: 3 modules (52.5mm)
Specifications
| Breaking Capacity | 15kA |
| Current Rating | 32A |
| Curve Type | Type B |
| EAN | 3250614618376 |
| Manufacturer Part Code | NBN332A |
| Mounting Type | DIN Rail |
| Number of Poles | 3 Pole |
| Product Range | NBN Series |
| Rated Voltage | 230V, 400V |
