Hager

25A Triple Pole 10kA MCB - Type C

Hager

25A Triple Pole 10kA MCB - Type C

Part Code: NCN325A

Stock Availability
Please contact your local store for details
FREE delivery over £50 ex. VAT
Product Details
Part Code: NCN325A
  • Provides protection against short circuits, protection against overload current, control, isolation, trip free mechanism
  • The state of isolation is clearly indicated by the “OFF” mechanical position on the toggle with the green colour
  • Connection capacity: 25mm² flexible conductor, 35mm² rigid conductor
  • Conforms to: BS EN 60898-2 (10kA), BS EN 60947-2 (15kA)
Downloads
Specifications
Breaking Capacity 15kA
Current Rating 25A
Curve Type Type C
EAN 3250614615849
EClass Code 27-07
Manufacturer Part Code NCN325A
Mounting Type DIN Rail
Number of Poles 3 Pole
Product Range NCN Series
Rated Voltage 230V, 400V
UNSPSC Code 39121603
