Hager

20A Triple Pole MCBs 10kA Type D

Part Code: NDN320A

Stock Availability
Please contact your local branch for details
Product Details
Part Code: NDN320A
  • Ensures protection of circuits against short circuits
  • Ensures protection of circuits against overload current
  • The state of isolation is clearly indicated by the "OFF" mechanical position on the toggle with the green colour

20A triple Pole MCB 10kA Type D. Complies with BS EN 60898 (10kA), BS EN 60947-2 (15kA). Voltage rating: 230 - 400V Connection capacity: Rigid conductor 35mm² Flexible conductor 25mm² Width : 1 module (17.5mm) 6A to 63A

Specifications
Breaking Capacity 15kA
Current Rating 20A
Curve Type Type D
EAN 3250614619250
Mounting Type DIN Rail
Number of Poles 3 Pole
Product Range NDN Series
Rated Voltage 230V, 400V
